NC7SZ04P5X

Name: NC7SZ04P5X
Brand: Fairchild/ON Semiconductor
SKU: 250060
Availability: InStock
Rating: 4.85 (378 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NC7SZ04P5X
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	Inverter 1-Element CMOS 5-Pin SC-70 T/R / IC INVERTER UHS SINGLE SC70-5
Datasheet	NC7SZ04P5X Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	1
Number of Inputs	1
Supply Voltage - Operating	1.65 V to 5.5 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	32mA, 32mA
Max Propagation Delay @ V, Max CL	4.3ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	SC-70-5
Dimension	5-TSSOP, SC-70-5, SOT-353
Win Source Part Number	024803-NC7SZ04P5X
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial
Quantity per package	3k pcs
Family Name	NC7SZ04
Introduction Date	November 16, 1999
ECCN	EAR99
Country of Origin	China, Malaysia , Philippines, Thailand
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian NC7SZ04P5X CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor 024803-NC7SZ04P5X electronic component is manufactured by Fairchild/ON Semiconductor and is a single circuit inverter with a maximum propagation delay of 4.3ns @ 5V and 50pF.

Package / Case: SC-70-5
Mounting Type: Surface Mount
Features: Reliable and durable component, small and compact design, easy to install, high performance, cost-effective solution, low power consumption
Application: Industrial Applications
Quantity Per Package: 3k pcs
