MOCD223R2M Real Image MOCD223R2M Real Image
Same model may have multiple batches, images only for reference.
MOCD223R2M Real Image MOCD223R2M Real Image
MOCD223R2M Real Image MOCD223R2M Real Image
Same model may have multiple batches, images only for reference.

MOCD223R2M

Part No MOCD223R2M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 2.5KV 2CH DARL 8SOIC
Datasheet
MOCD223R2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Supply and Demand Status Balance
Quantity per package 2,500
Popularity Medium
Win Source Part Number 024204-MOCD223R2M
Case / Package 8-SO Tall
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 100°C
Vce Saturation (Max) 1V
Continuous forward current- Max 60mA
Forward Voltage 1.25V
Channel Output Current 150mA
Maximum Output Voltage 30V
Output Type Darlington
Input Type DC
Rise and Fall Time 8μs, 110μs
Switching Turn-On and Turn-Off Time 10μs, 125μs
Minimum DC Current Transfer Ratio 500% @ 1mA
Isolation Voltage 2500Vrms
Number of Channels 2
Status Active
Packaging Reel - TR
Manufacturer Fairchild/ON Semiconductor
Categories Isolators
Ultra Librarian 3D Model Ultra Librarian MOCD223R2M CAD Model

Description

The 024204-MOCD223R2M is a dual-channel optocoupler from Fairchild/ON Semiconductor.

  • Isolation Voltage: 2500Vrms
  • Minimum DC Current Transfer Ratio: 500% @ 1mA
  • Switching Turn-On Time: 10μs
  • Switching Turn-Off Time: 125μs
  • Rise Time: 8μs
  • Fall Time: 110μs
  • Maximum Output Voltage: 30V
  • Channel Output Current: 150mA
  • Continuous Forward Current-Max: 60mA
  • Operating Temperature Range: from -40°C to 100°C
  • Package: 8-SO Tall
  • Packaging: reel of 2500 pieces
  • Ideal Use: isolators
