MMSZ5242B Real Image MMSZ5242B real image3515
Same model may have multiple batches, images only for reference.
MMSZ5242B Real Image MMSZ5242B real image3515
MMSZ5242B Real Image MMSZ5242B real image3515
Same model may have multiple batches, images only for reference.

MMSZ5242B

Part No MMSZ5242B
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes - Zener - Single
Description DIODE ZENER 12V 500MW SOD123
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Fairchild Semiconductor
Standard Package 1
Category Discrete Semiconductor Products
Family Diodes - Zener - Single
Packaging Reel
Voltage - Zener (Nom) (Vz) 12V
Tolerance ±5%
Power - Max 500mW
Impedance (Max) (Zzt) 30 Ohm
Current - Reverse Leakage @ Vr 1µA @ 9.1V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Operating Temperature Range -55°C ~ 150°C
Mounting Style SMD/SMT
Package SOD-123
Manufacturer Device Package SOD-123
Catalog MMSZ Zener Diode
Win Source Part Number 084304-MMSZ5242B
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Package Tape & Reel (TR)
Product Status Active
Impedance (Max) (Zzt) 30 Ohms
Operating Temperature -65°C ~ 150°C (TJ)
Grade -
Mounting Type Surface Mount
Package / Case SOD-123F
Supplier Device Package SOD-123F
Ultra Librarian 3D Model Ultra Librarian MMSZ5242B CAD Model

Description

The Fairchild Semiconductor is a discrete semiconductor product with a win source part number of 084304-MMSZ5242B.

  • Win Source Part Number: 084304-MMSZ5242B
  • Family: diodes - zener - single
  • Packaging: reel
  • Operating Temperature Range: -55°C to 150°C
  • Package: SOD-123
  • Manufacturer Device Package: SOD-123
  • Standard Package: 1
  • Tolerance: ±5%
  • Power - Max: 500mW
  • Voltage - Forward (Vf) (Max) @ If: 900mV @ 10mA
  • Current - Reverse Leakage @ Vr: 1µA @ 9.1V
  • Voltage - Zener (Nom) (Vz): 12V
  • Impedance (Max) (Zzt): 30 Ohm
  • Supply and Demand Status: balance
