H11G3SR2M Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

H11G3SR2M

Part No H11G3SR2M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 7.5KV DARL W/BASE 6SMD
Datasheet
H11G3SR2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Obsolete(EOL)
Number of Channels 1
Isolation Voltage 7500Vpk
Minimum DC Current Transfer Ratio 200% @ 1mA
Switching Turn-On and Turn-Off Time 5μs, 100μs
Input Type DC
Output Type Darlington with Base
Maximum Output Voltage 55V
Forward Voltage 1.3V
Continuous forward current- Max 60mA
Vce Saturation (Max) 1.2V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 6-SMD
Win Source Part Number 1042190-H11G3SR2M
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian H11G3SR2M CAD Model

Description

The H11G3SR2M is a Darlington with base output type isolator manufactured by Fairchild/ON Semiconductor.

  • Packaging: Reel - TR
  • Mounting Type: SMD (SMT)
  • Input Type: DC
  • Channel: One
  • Forward Voltage: 1.3V
  • Vce Saturation (Max): 1.2V
  • Isolation Voltage: 7500Vpk
  • Operating Temperature: -40°C to 100°C
  • Case/Package Size: 6-SMD
  • DC Current Transfer Ratio (Min): 200% @ 1mA
  • Switching Turn-On Time: 5μs
  • Switching Turn-Off Time: 100μs
  • Output Voltage (Max): 55V
  • Continuous Forward Current- Max: 60mA
  • Part Status: Obsolete (EOL)
  • Popularity: Medium
  • Quantity per Package: 1k pcs
