MMBD1403

Part No MMBD1403
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Arrays
Description Rectifier Diode Small Signal Switching 200V 0.2A 50ns 3-Pin SOT-23 T/R / DIODE ARRAY GP 200V 200MA SOT23
Datasheet
MMBD1403 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Series Connection
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) (per Diode) 200mA
Voltage - Forward (Vf) (Max) @ If 1V @ 200mA
Reverse Recovery Time (trr) 50ns
Current - Reverse Leakage @ Vr 100nA @ 175V
Operating Temperature - Junction 150°C (Max)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 023645-MMBD1403
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Family Name MMBD1403
Introduction Date May 03, 1998
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MMBD1403 CAD Model

Description

The Fairchild/ON Semiconductor 023645-MMBD1403 is a standard diode used in discrete semiconductor products.

  • Voltage Rating (DC Reverse): 200V
  • Voltage Rating (Forward): 1V @ 200mA
  • Reverse Recovery Time: 50ns
  • Current Leakage: 100nA @ 175V
  • Diode Configuration: 1 pair series connection
  • Mounting Technology: SMD (SMT)
  • Case/Package: SOT-23-3
  • Popularity: High
  • Supply and Demand: Sufficient
