L272M Fairchild/ON Semiconductor L272M real image671 L272M Real Image
Same model may have multiple batches, images only for reference.
L272M Fairchild/ON Semiconductor L272M real image671 L272M Real Image
L272M Fairchild/ON Semiconductor L272M real image671 L272M Real Image
Same model may have multiple batches, images only for reference.

L272M

Part No L272M
Manufacturer Fairchild/ON Semiconductor
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 2 CIRCUIT 8MINI DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Mfr Fairchild/ON Semiconductor
Package Bulk
Product Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 1V/µs
Gain Bandwidth Product 350 kHz
Current - Input Bias 300 nA
Voltage - Input Offset 15 mV
Current - Supply 8mA
Current - Output / Channel 700 mA
Voltage - Supply Span (Min) 4 V
Voltage - Supply Span (Max) 28 V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Through Hole
Package / Case 8-DIP (0.300", 7.62mm)
Supplier Device Package 8-Mini DIP
Standard Package 1 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Win Source Part Number 172392-L272M
Ultra Librarian 3D Model Ultra Librarian L272M CAD Model

Description

The L272M is a dual operational amplifier (op amp) integrated circuit (IC) that is commonly used in instrumentation, op amp, and buffer amplifier applications.

  • Package: 8-DIP
  • Temperature Range: -40°C to 85°C
  • Slew Rate: 1V/μs
  • Gain Bandwidth Product: 350kHz
  • Current Input Bias: 300nA
  • Input Offset Voltage: 15mV
  • Current Supply: 8mA
  • Current Output: 700mA per channel
  • Mounting: Through-hole
