HCPL2630SD Real Image HCPL2630SD real image4565
Same model may have multiple batches, images only for reference.
HCPL2630SD Real Image HCPL2630SD real image4565
HCPL2630SD Real Image HCPL2630SD real image4565
Same model may have multiple batches, images only for reference.

HCPL2630SD

Part No HCPL2630SD
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Logic Output
Description OPTOISO 2.5KV 2CH OPEN COLL 8SMD
Datasheet
HCPL2630SD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 10kV/μs (Typ)
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 50ns, 12ns
Forward Voltage 1.4V
Continuous forward current- Max 30mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SMD
Win Source Part Number 101319-HCPL2630SD
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL2630SD CAD Model

Description

The Fairchild/ON Semiconductor HCPL2630SD is a 2-channel, open-collector output type optocoupler. It has a data rate of 10Mbps and a common mode transient immunity of 10kV/μs (Typ). The propagation delay tpLH / tpHL (Max) for the optocoupler is 75ns. It has an isolation voltage of 2500Vrms and is packaged in an 8-SMD package. The optocoupler has a temperature range of -40°C to 85°C and a supply voltage of 4.5V to 5.5V. It is ideal for use in isolator applications.
