FODM8061 Real Image FODM8061 real image15465
Same model may have multiple batches, images only for reference.
FODM8061 Real Image FODM8061 real image15465
FODM8061 Real Image FODM8061 real image15465
Same model may have multiple batches, images only for reference.

FODM8061

Part No FODM8061
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPEN COLL 5MFP
Datasheet
FODM8061 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 20kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Max) 80ns, 80ns
Rise and Fall Time 20ns, 10ns
Forward Voltage 1.45V
Continuous forward current- Max 50mA
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 110°C
Mounting SMD (SMT)
Case / Package 5-Mini-Flat
Win Source Part Number 1039451-FODM8061
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FODM8061 CAD Model

Description

The Fairchild/ON Semiconductor FODM8061 is an isolator designed for use in electronic circuits. Bold the product name (e.g., FODM8061) and manufacturer (e.g., Fairchild/ON Semiconductor).

  • Isolation Voltage: 3750Vrms
  • Common Mode Transient Immunity: 20kV/μs
  • Data Rate: 10Mbps
  • Rise and Fall Time: 20ns, 10ns
  • Packaging: 5-Mini-Flat
  • Temperature Range: -40°C to 110°C
  • Output Type: Open Collector and Schottky Clamped
  • Forward Voltage: 1.45V
  • Channel Output Current: 50mA
  • Supply and Demand: Balanced
  • Package Quantity: 3k pcs
