FGH40N60SFTU

Part No FGH40N60SFTU
Manufacturer Fairchild/ON Semiconductor
Catalog IGBTs - Single
Description IGBT 600V 80A 290W TO247
Datasheet
FGH40N60SFTU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
IGBT Type Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 80A
Pulsed Collector Current 120A
Collector-emitter saturation voltage(Max) 2.9V @ 15V, 40A
Maximum Power Dissipation 290W
Total Switching Energy(Ets) 1.13mJ (on), 310μJ (off)
Input Type Standard
Gate Charge 120nC
Turn-on and Turn-off delay time 25ns/115ns
Testing Conditions 400V, 40A, 10 Ohm, 15V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247
Win Source Part Number 083565-FGH40N60SFTU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 450
Ultra Librarian 3D Model Ultra Librarian FGH40N60SFTU CAD Model

Description

The FGH40N60SFTU is an IGBT transistor manufactured by Fairchild/ON Semiconductor. It is a field stop IGBT type.

  • Collector-Emitter Breakdown Voltage (Max): 600V
  • Current Collector (Max): 80A
  • Gate Charge: 120nC
  • Package: TO-247
  • Popularity: High
  • Total Switching Energy: 1.13mJ (on), 310μJ (off)
  • Turn-On/Turn-Off Delay Time: 25ns / 115ns
  • Quantity per Package: 450
