FFD10UP20S Real Image FFD10UP20S Real Image1 FFD10UP20S Real Image2 FFD10UP20S Real Image3
Same model may have multiple batches, images only for reference.
FFD10UP20S Real Image FFD10UP20S Real Image1 FFD10UP20S Real Image2 FFD10UP20S Real Image3
FFD10UP20S Real Image FFD10UP20S Real Image1 FFD10UP20S Real Image2 FFD10UP20S Real Image3
Same model may have multiple batches, images only for reference.

FFD10UP20S

Part No FFD10UP20S
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 200V 10A DPAK
Datasheet
FFD10UP20S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) 10A
Voltage - Forward (Vf) (Max) @ If 1.15V @ 10A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 20.8ns
Current - Reverse Leakage @ Vr 100μA @ 200V
Mounting SMD (SMT)
Case / Package TO-252AA
Operating Temperature - Junction -65°C to 175°C
Win Source Part Number 001155-FFD10UP20S
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FFD10UP20S CAD Model

Description

The Fairchild/ON Semiconductor FFD10UP20S is a standard diode.

  • Maximum DC Reverse Voltage: 200V
  • Average Rectified Current: 10A
  • Fast Recovery Speed: 200mA (Io)
  • Voltage Forward: 1.15V at 10A
  • Reverse Recovery Time: 20.8ns
  • Reverse Leakage Current: 100μA at 200V
  • Package: TO-252AA
  • Operating Temperature Range: -65°C to 175°C
  • Commonly Used in: Discrete semiconductor products
  • Demand: High
  • Supply and Demand: Balance
