FAN5606DMPX Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

FAN5606DMPX

Part No FAN5606DMPX
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - LED Drivers
Description IC LED DRVR RGLTR DIM 20MA 8MLP
Datasheet
FAN5606DMPX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Obsolete(EOL)
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Operating Input Voltage(Min) 2.7V
Maximum Supply Voltage 5.5V
Output Voltage 18V
Channel Output Current 20mA
Frequency 500kHz
Dimming Analog, PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-MLP (3x3)
Win Source Part Number 131592-FAN5606DMPX
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian FAN5606DMPX CAD Model

Description

Description

The FAN5606DMPX LED driver offers a compact solution for efficient power management in lighting applications. It is specifically optimized for high-brightness LED arrays, ensuring stable performance across a range of operating conditions.

Features and Benefits

  • Optimized for high-brightness LEDs
  • Flexible configuration options
  • Over-voltage protection for safety
  • Efficient power management features

Applications/Projects

  • Smartphone and tablet backlighting
  • Digital signage and advertisement displays
  • Automotive dashboard lighting
  • Architectural lighting systems
