BAT54SWT1G Real Image BAT54SWT1G real image2465 BAT54SWT1G real image2466 BAT54SWT1G real image2467 BAT54SWT1G Real Image
Same model may have multiple batches, images only for reference.
BAT54SWT1G Real Image BAT54SWT1G real image2465 BAT54SWT1G real image2466 BAT54SWT1G real image2467 BAT54SWT1G Real Image
BAT54SWT1G Real Image BAT54SWT1G real image2465 BAT54SWT1G real image2466 BAT54SWT1G real image2467 BAT54SWT1G Real Image
Same model may have multiple batches, images only for reference.

BAT54SWT1G

Part No BAT54SWT1G
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 30V SOT323
Datasheet
BAT54SWT1G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Series Connection
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) (per Diode) 200mA (DC)
Voltage - Forward (Vf) (Max) @ If 800mV @ 100mA
Reverse Recovery Time (trr) 5ns
Current - Reverse Leakage @ Vr 2μA @ 25V
Operating Temperature - Junction -55°C to 150°C
Mounting SMD (SMT)
Case / Package SOT-323
Win Source Part Number 011006-BAT54SWT1G
Family Name BAT54SW
Introduction Date October 21, 1997
ECCN EAR99
Country of Origin China, Morocco
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Safety
Ultra Librarian 3D Model Ultra Librarian BAT54SWT1G CAD Model

Description

The BAT54SWT1G is an industry-standard Schottky diode featuring a dual-diode array in a compact SOT-323 package. Known for its low power loss and high-efficiency characteristics, it is perfect for cutting-edge electronic designs.

Features and Benefits

  • Low forward voltage drop: Increases efficiency in energy-sensitive applications.
  • Compact dual-diode design: Saves space and facilitates easy installation.
  • High-speed switching: Suitable for dynamic signal processing.

Applications

  • Battery chargers
  • Polarity protection circuits
  • Signal demodulation
  • Power supply rectification

The BAT54SWT1G's robust performance and versatility make it an ideal choice for modern electronics, providing superior performance and reliability.
