6678505021 FAIR-RITE PRODUCTS – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

6678505021

Part No 6678505021
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE PQ 78 SET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type PQ
Material 78
Tolerance ±25%
Gap Ungapped
Initial Permeability (µi) 2300
Core Factor (ΣI/A) mm⁻¹ 35.9
Effective Length (le) mm 114.7
Effective Area (Ae) mm2 319.0
Minimum Core Cross Section (Amin) mm2 314.2
Effective Magnetic Volume (Ve) mm3 36630.0
Finish Uncoated
Length 1.969" (50.00mm)
Width 1.260\
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1528117-6678505021
Ultra Librarian 3D Model Ultra Librarian 6678505021 CAD Model
