5977000101 FAIR-RITE PRODUCTS – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

5977000101

Part No 5977000101
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE TOROID 77
Datasheet
5977000101 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type Toroid
Material 77
Diameter 0.230" (5.84mm)
Tolerance ±25%
Gap Ungapped
Initial Permeability (µi) 2000
Effective Length (le) mm 13.0
Effective Area (Ae) mm2 2.0
Effective Magnetic Volume (Ve) mm3 27.0
Finish Uncoated
Height 0.060" (1.52mm)
Package Box
Supply and Demand Status Normal
Win Source Part Number 1528096-5977000101
Ultra Librarian 3D Model Ultra Librarian 5977000101 CAD Model
