Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Connectors
Estimated Pruduction Lead Time 2 Weeks
Features 26 Position Receptacle Connector 0.050" (1.27mm) Surface Mount Gold
Manufacturer ERNI Electronics
Series SMC
Package Reel - TR
Operating Temperature Range -55°C ~ 125°C
Mounting Surface Mount
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number 2684-124044DKR, 2684-124044CT, 2684-124044TR
Quantity per package 280
Popularity High
Supply and Demand Status Balance
Win Source Part Number 905260-124044
Ultra Librarian 3D Model Ultra Librarian 124044 CAD Model

Description

The ERNI Electronics 905260-124044 is a surface mount gold connector with 26 position receptacle.

  • Positions: 26
  • Series: SMC
  • Operating Temperature Range: -55°C ~ 125°C
  • Estimated Production Lead Time: 2 weeks
  • Quantity per Package: 280
  • Manufacturer Homepage: www.erni.com
  • Win Source Part Number: 905260-124044
