Same model may have multiple batches, images only for reference.
WCL3225-R82-R Real Image
Same model may have multiple batches, images only for reference.

WCL3225-R82-R

Part No WCL3225-R82-R
Manufacturer Eaton Bussmann
Catalog Fixed Inductors
Description FIXED IND 820NH 450MA 300MOHM SM / 820 nH Unshielded Drum Core, Wirewound Inductor 450 mA 300mOhm Max 1210 (3225 Metric)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Eaton - Electronics Division
Series WCL3225
Package Tape & Reel (TR)
Type Drum Core, Wirewound
Material - Core Ceramic
Inductance 820 nH
Tolerance ±5%
Current Rating (Amps) 450 mA
Shielding Unshielded
DC Resistance (DCR) 300mOhm Max
Q @ Freq 20 @ 25.2MHz
Frequency - Self Resonant 350MHz
Temperature Range - Operating -40°C ~ 85°C
Inductance Frequency - Test 25.2 MHz
Mounting SMD (SMT)
Package / Case 1210 (3225 Metric)
Supplier Device Package 1210
Dimension 0.138" L x 0.114" W (3.50mm x 2.90mm)
Height - Seated (Max) 0.089" (2.25mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Other Names 283-WCL3225-R82-RTR
Standard Package 2,000
Win Source Part Number 983696-WCL3225-R82-R
Ultra Librarian 3D Model Ultra Librarian WCL3225-R82-R CAD Model

Description

The WCL3225-R82-R from Eaton - Electronics Division is a fixed inductor with a ceramic core and a tolerance of ±5%.

  • Type: Fixed Inductor
  • Core Material: Ceramic
  • Tolerance: ±5%
  • Inductance: 820 nH
  • DC Resistance: 300mOhm Max
  • Current Rating: 450 mA
  • Height: 0.089" (2.25mm)
  • Dimensions: 0.138" L x 0.114" W (3.50mm x 2.90mm)
  • Packaging: Tape & Reel
  • Shielding: Unshielded
  • MSL Level: 1 (unlimited)
  • HTSUS: 8504.50.8000
