170M3442 Real Image
Same model may have multiple batches, images only for reference.

170M3442

Part No 170M3442
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE SQUARE 125A 1.3KVAC RECT / 125A 1.3 kV AC DC Fuse Square Holder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Package Bulk
Mounting Type Holder
Fuse Type Square
Current Rating (Amps) 125A
Voltage Rating - AC 1.3 kV
Applications Electrical, Industrial
Features Indicating
Approval Agency CSA, UR
Breaking Capacity @ Rated Voltage 100kA
Package / Case Rectangular, Blade
Dimension 2.323" L x 1.772" W x 3.189" H (59.00mm x 45.00mm x 81.00mm)
Melting I2t 1450
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8535.10.0040
Standard Package 3
Win Source Part Number 997934-170M3442
Ultra Librarian 3D Model Ultra Librarian 170M3442 CAD Model

Description

The Eaton - Bussmann Electrical Division 997934-170M3442 is a square indicating fuse that is designed to protect electrical and industrial applications from overcurrent.

  • Indicating: Square
  • Voltage Rating: 1.3 kV AC
  • Breaking Capacity: 100kA @ rated voltage
  • Current Rating: 125A
  • Melting I2t: 1450
  • Package/Case: Rectangular, Blade
  • Dimensions: 2.323" L x 1.772" W x 3.189" H (59.00mm x 45.00mm x 81.00mm)
  • HTSUS Code: 8535.10.0040
  • Approvals: CSA and UR
