KC24B30.001SLS E-Switch – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

KC24B30.001SLS

Part No KC24B30.001SLS
Manufacturer E-SWITCH
Catalog Rotary Switches
Description SWITCH ROTARY 4POS 350MA 125V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Positions 4
Index Stops Fixed
Number of Decks 1
Number of Poles per Deck 2
Circuit per Deck DP4T
Contact Timing Shorting (MBB)
Current Rating (Amps) 350mA (AC)
Voltage Rating - AC 125 V
Actuator Type Round (6mm Dia)
Actuator Length 30.00mm
Angle of Throw 30°
Contact Material Copper Alloy
Contact Finish Silver
Mounting Type Panel Mount
Termination Style Solder Lug
Depth Behind Panel 18.50mm
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1559499-KC24B30.001SLS
Ultra Librarian 3D Model Ultra Librarian KC24B30.001SLS CAD Model
