The PI6C4911506LIE is a high-performance clock buffer from Diodes Incorporated designed to meet the demands of modern electronic systems. This clock buffer is a part of Diodes Incorporated's precision integrated circuit range, providing reliable and stable clock distribution for a variety of applications.
Key Features
- Multiple Outputs: The device features six LVDS outputs, ensuring multiple devices can be synchronized within a system.
- Low Jitter Performance: With its low jitter characteristic, the PI6C4911506LIE ensures high-quality signal integrity, which is crucial for high-speed communication and data processing.
- Wide Frequency Range: It supports a wide range of frequencies, making it versatile for use in different applications that require varying clock speeds.
- Power Efficiency: The device is designed for low power consumption, contributing to the overall energy efficiency of the systems it is integrated into.
Applications
The PI6C4911506LIE is suitable for various applications, including but not limited to:
- Networking equipment such as routers, switches, and network interface cards
- Data center servers and storage systems
- Telecommunication infrastructure
- High-performance computing and data processing units
Technical Specifications
| Parameter |
Value |
| Supply Voltage (VDD) |
3.3V ±0.3V |
| Operating Temperature Range |
-40°C to 85°C |
| Package |
40-lead TQFN |
| Phase Jitter (Typical) |
Sub 50 fs |
Quality and Reliability
Diodes Incorporated is committed to delivering high-quality products. The PI6C4911506LIE is manufactured under strict quality control standards and is designed for high reliability and performance consistency over its operational life.
Ordering Information
For ordering the PI6C4911506LIE or to obtain more information about this clock buffer, interested parties can visit the Diodes Incorporated website or contact their local sales representative. The product is available in a 40-lead TQFN package, which is suitable for surface mount technology (SMT) assembly processes.
