DMC3060LVT-7 - Diodes Incorporated

The DMC3060LVT-7 is a high-performance, enhancement mode field-effect transistor (MOSFET) from Diodes Incorporated. This MOSFET is a part of the company's extensive line of power management devices, designed to cater to a broad range of applications, including but not limited to power supplies, DC-DC converters, and motor drives.

Key Features

• Device Type: MOSFET
• Channel Type: N-Channel
• Configuration: Single
• Drain-Source Voltage (V<sub>DS): 30V
• Continuous Drain Current (I<sub>D): 8A
• Power Dissipation (P<sub>D): 2.5W
• R<sub>DS(on): As low as 20mΩ at V<sub>GS = 10V
• Operating Temperature: -55°C to +150°C
• Package / Case: SOT-23-6L

Advanced Technology

The DMC3060LVT-7 utilizes advanced trench technology to provide excellent R<sub>DS(on) with low gate charge. This results in a device that not only conserves energy but also optimizes the efficiency of the system it is incorporated into. The low threshold voltage ensures that the MOSFET can be driven at lower voltages, making it suitable for low-voltage applications.

High Reliability

Diodes Incorporated has designed the DMC3060LVT-7 with reliability in mind. It features a robust and durable construction that can withstand high energy pulses in the avalanche and commutation mode, which is critical for demanding applications. Additionally, the MOSFET is characterized by its high thermal performance, which ensures stability and longevity even under varying environmental conditions.

Applications

With its compact SOT-23-6L package, the DMC3060LVT-7 is ideal for space-constrained applications. It is widely used in power management tasks for portable devices, consumer electronics, and other systems where efficient power conversion is necessary. Its fast switching speed and low on-resistance make it a preferred choice for high-efficiency power applications.

For detailed specifications, application notes, and additional resources, interested parties are encouraged to visit the Diodes Incorporated official website or contact their local sales representative.
