Product Overview: 74LVC2G02HK3-7 from Diodes Incorporated

The 74LVC2G02HK3-7 is a high-performance, dual 2-input NOR gate integrated circuit, brought to you by Diodes Incorporated, a leading manufacturer in the semiconductor industry. This product is designed to operate with a power supply range of 1.65V to 5.5V, making it compatible with a variety of logic systems and ideal for battery-operated applications due to its low power consumption.

Constructed with advanced silicon-gate CMOS technology, the 74LVC2G02HK3-7 offers robust performance with high-speed operation while maintaining low static power dissipation. The device is characterized for operation from -40°C to +125°C, ensuring reliable functionality across a wide range of environmental conditions. This makes it suitable for industrial, automotive, and consumer electronics where temperature resilience is crucial.

Key features of the 74LVC2G02HK3-7 include:

• Logic Type: Dual 2-Input NOR Gate
• Supply Voltage Range: 1.65V to 5.5V
• Operating Temperature: -40°C to +125°C
• Output Capability: Standard
• Mounting Type: Surface Mount
• Package / Case: SOT-363
• High Noise Immunity: Ensures stable operation in electrically noisy environments
• Low Power Dissipation: Ideal for power-sensitive applications
• 5V Tolerant Inputs: Inputs can tolerate up to 5V even when operating at lower voltages
• Latch-Up Performance: Exceeds 250mA per JESD 78, Class II
• ESD Protection: HBM JESD 22-A114F exceeds 2000V and MM JESD 22-A115-A exceeds 200V

The device is delivered in a compact SOT-363 package, which is optimal for space-constrained applications. Its small form factor and surface-mount design make it a practical choice for modern high-density electronic assemblies.

Whether you're designing sophisticated computing systems, telecommunications equipment, or portable electronics, the 74LVC2G02HK3-7 from Diodes Incorporated is a reliable and efficient solution for implementing basic logic functions with the added benefit of high noise immunity and protection features. Its versatility and performance characteristics ensure that it is an excellent choice for a wide array of applications that require the utmost in logic processing reliability.
