Diodes Incorporated 74LVC1G04SE-7 Single Inverter

The 74LVC1G04SE-7 is a high-performance, single inverter gate designed and manufactured by Diodes Incorporated, a leading global manufacturer and supplier of high-quality application-specific standard products within the broad discrete, logic, and analog semiconductor markets. This device is part of the 74LVC family, which is known for its low-voltage operation and compatibility with mixed-voltage systems.

Key Features

• Low Voltage Operation: The 74LVC1G04SE-7 operates at a very low voltage range of 1.65V to 5.5V, making it suitable for battery-operated and portable devices where power efficiency is crucial.
• High-Speed Performance: Despite its low power consumption, this inverter does not compromise on speed, providing a balanced propagation delay and transition times.
• 5V Tolerant Inputs: Inputs are 5V tolerant, allowing the device to be used in mixed-voltage environments without the need for additional level shifting.
• Low Power Dissipation: It has an extremely low static power consumption, with a typical ICC of only 0.1µA, significantly reducing the overall power usage of the system.
• ESD Protection: The device includes robust electrostatic discharge (ESD) protection, ensuring reliability and longevity even in environments where ESD events may occur.

Applications

The versatility of the 74LVC1G04SE-7 makes it an ideal choice for a wide range of applications including:

• Logic level translation
• Signal inversion
• Function generation
• Wave shaping
• Oscillator circuits

Package and Quality

The 74LVC1G04SE-7 comes in a small SOT-353 package, which is suitable for automated surface-mount assembly processes and space-constrained applications. The product adheres to the stringent quality standards set by Diodes Incorporated, ensuring high reliability and performance consistency.

Whether you are designing consumer electronics, communication devices, or complex computing systems, the 74LVC1G04SE-7 from Diodes Incorporated provides a compact, efficient, and reliable solution for your inverting needs.
