DTU50N03

Part No DTU50N03
Manufacturer DinTek Semiconductor Co,.Ltd
Catalog END - OF - LIFE
Description Halogen-free According to IEC 61249-2-21
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer DinTek Semiconductor Co,.Ltd
Win Source Part Number 1170452-DTU50N03
Manufacturer Homepage www.daysemi.jp/
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DTU50N03 CAD Model

Description

The DTU50N03 is an N-Channel enhancement mode power MOSFET from DinTek Semiconductor Co., Ltd. It is designed for high-efficiency switching applications and features a low on-resistance for reduced power loss. This MOSFET is suitable for various power management and load switching tasks.

Applications:

  • DC-DC converters
  • Power management circuits
  • Load switching
  • Motor control
  • LED lighting

Features:

  • N-Channel enhancement mode
  • Low on-resistance (RDS(on))
  • High switching speed
  • High avalanche ruggedness
  • RoHS compliant

Benefits:

  • Improved power efficiency due to low on-resistance
  • Reduced power loss and heat generation
  • Fast switching performance for high-frequency applications
  • Enhanced system reliability due to avalanche ruggedness
  • Environmentally friendly due to RoHS compliance

Technical Specifications:

The DTU50N03 typically features a drain-source voltage (VDS) of 30V, a continuous drain current (ID) of 50A, and a gate-source voltage (VGS) of ±20V. The on-resistance (RDS(on)) is typically around 4.5 mΩ at VGS = 10V. It is available in a TO-252 package. These parameters can vary, so refer to the specific datasheet for precise values.

Given its END-OF-LIFE status, finding direct replacements may be necessary for new designs. Consider similar MOSFETs from other manufacturers with comparable specifications.
