CYRF69103-40LFXC Cypress Semiconductor Corp CYRF69103-40LFXC Real Image CYRF69103-40LFXC label picture CYRF69103-40LFXC label picture 2 CYRF69103-40LFXC label picture 3
Same model may have multiple batches, images only for reference.
CYRF69103-40LFXC Cypress Semiconductor Corp CYRF69103-40LFXC Real Image CYRF69103-40LFXC label picture CYRF69103-40LFXC label picture 2 CYRF69103-40LFXC label picture 3
CYRF69103-40LFXC Cypress Semiconductor Corp CYRF69103-40LFXC Real Image CYRF69103-40LFXC label picture CYRF69103-40LFXC label picture 2 CYRF69103-40LFXC label picture 3
Same model may have multiple batches, images only for reference.

CYRF69103-40LFXC

Part No CYRF69103-40LFXC
Manufacturer Cypress Semiconductor Corp
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU ISM>1GHZ 40-VFQFN
Datasheet
CYRF69103-40LFXC Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Cypress Semiconductor Corp
Packaging Tray
Status Obsolete(EOL)
Type TxRx + MCU
RF Family/Standard General ISM > 1GHZ
Modulation DSSS, GFSK
Frequency 2.4GHz
Data Rate (Max) 1Mbps
Power - Output 4dBm
Sensitivity -97dBm
Memory Size 8kB Flash, 256B SRAM
Serial Interfaces SPI
GPIO 15
Supply Voltage - Operating 1.8 V to 3.6 V
Current - Receiving 18.9mA to 21.9mA
Current - Transmitting 21.2mA to 39.9mA
Temperature Range - Operating 0°C to 70°C
Dimension 40-VFQFN Exposed Pad
Win Source Part Number 080296-CYRF69103-40LFXC
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name CYRF69103
Introduction Date June 13, 2005
ECCN 5A991.g
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian CYRF69103-40LFXC CAD Model

Description

Product Overview

The CYRF69103-40LFXC is engineered to deliver optimal performance in wireless communication systems. With its robust design and high efficiency, it provides excellent connectivity solutions in diverse settings.

Features and Benefits

  • Exceptional wireless communication range
  • High data transmission rates
  • Secure and reliable connections
  • Energy-efficient design
  • Built-in error correction technology

Applications

  • Wireless networking
  • Remote monitoring systems
  • Consumer electronics
  • Smart home devices
  • Industrial wireless control

Whether for industrial or personal use, the CYRF69103-40LFXC offers superior technology to keep systems connected and efficient.
