1520 Data Delay Devices, Inc.
Same model may have multiple batches, images only for reference.

1520

Part No 1520
Manufacturer Curtis Industries
Catalog Terminal Blocks
Description CONN BARRIER STRP 20CIRC 0.375"
Datasheet
1520 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Terminal Blocks - Barrier Blocks
Mfr Curtis Industries
Series 1500
Package Bulk
Product Status Active
Terminal Block Type Barrier Block
Number of Circuits 20
Number of Wire Entries 40
Pitch 0.375" (9.53mm)
Number of Rows 2
Current Rating (Amps) 20A
Wire Gauge 10-22 AWG
Top Termination Screws
Bottom Termination Closed
Barrier Type 2 Wall (Dual)
Features Flange
Terminal Screw Material Steel
Mounting Type Chassis, Panel
Temperature Range - Operating 110°C
Material - Insulation Polyphenylene Oxide (PPO)
Material Flammability Rating UL94 V-0
Standard Package 25 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 538610-1520
Ultra Librarian 3D Model Ultra Librarian 1520 CAD Model

Description

The 538610-1520 is a barrier block terminal block used in connector and interconnect applications.

  • Series: 1500
  • Pitch: 0.375" (9.53mm)
  • Rows: Two
  • Wire Gauge: 10-22 AWG
  • Current Rating: 20A
  • Insulation Material: Polyphenylene Oxide (PPO)
  • Flammability Rating: UL94 V-0
  • Temperature Range: 110°C
  • Mounting: Chassis/Panel
  • Manufacturer: Curtis Industries
  • Product Status: Active
