Same model may have multiple batches, images only for reference.
PEM1-S12-S5-S Real Image
Same model may have multiple batches, images only for reference.

PEM1-S12-S5-S

Part No PEM1-S12-S5-S
Manufacturer CUI Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V 1W / Isolated Module DC DC Converter 1 Output 5V 200mA 10.8V - 13.2V Input
Datasheet
PEM1-S12-S5-S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Manufacturer CUI Inc.
Packaging Tube
Product Status Not For New Designs
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 1 5V
Current - Output (Max) 200mA
Power (Watts) 1 W
Voltage - Isolation 3 kV
Applications ITE (Commercial)
Features SCP
Temperature Range - Operating -40°C ~ 105°C
Efficiency 80%
Mounting Through Hole
Case / Package 7-SIP Module, 4 Leads
Size / Dimension 0.77" L x 0.24" W x 0.37" H (19.5mm x 6.0mm x 9.3mm)
Approval Agency CB Scheme, EN, IEC, UL
Standard Number 55024; 55032 Class A; 60950-1; 61000-3-2; 61000-3-3
Base Product Number PEM1-S12
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Part Number 102-2764,PEM1S12S5S
Standard Package 25
Win Source Part Number 1320569-PEM1-S12-S5-S
Ultra Librarian 3D Model Ultra Librarian PEM1-S12-S5-S CAD Model

Description

The PEM1-S12-S5-S is a 1W isolated module DC-DC converter with SCP feature.

  • Power: 1W
  • Isolated Module: Yes
  • Feature: SCP
  • Voltage Isolation: 3kV
  • Standard Package: 25
  • Size: 0.77" L x 0.24" W x 0.37" H
  • Application: ITE (Commercial)
  • Mounting Type: through-hole
  • Maximum Output Current: 200mA
  • Input Voltage Range: 10.8V to 13.2V
  • Output Voltage: 5V
  • Efficiency: 80%
  • Operating Temperature: -40°C to 105°C
  • RoHS Compliant: Yes
  • Approvals: CB Scheme, EN, IEC, and UL
