C4D15120D Cree Inc.
Same model may have multiple batches, images only for reference.

C4D15120D

Part No C4D15120D
Manufacturer Cree/Wolfspeed
Catalog Diodes, Rectifiers - Arrays
Description DIODE SCHOTTKY 1.2KV 24.5A TO247
Datasheet
C4D15120D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Cree/Wolfspeed
Series Z-Rec®
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology SiC (Silicon Carbide) Schottky
Voltage - DC Reverse (Vr) (Max) 1200 V
Current - Average Rectified (Io) (per Diode) 24.5V (DC)
Voltage - Forward (Vf) (Max) @ If 1.8 V @ 8 A
Speed No Recovery Time > 500mA (Io)
Current - Reverse Leakage @ Vr 250 µA @ 1200 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package TO-247-3
Base Product Number C4D15120
Standard Package 30 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 575825-C4D15120D
Ultra Librarian 3D Model Ultra Librarian C4D15120D CAD Model

Description

The 575825-C4D15120D is a high-performance rectifier from the Z-Rec™ series diode array, manufactured by Cree/Wolfspeed.

  • Technology: SiC (Silicon Carbide) Schottky
  • Maximum DC Reverse Voltage: 1200V
  • Forward Voltage: 1.8V @ 8A
  • Reverse Leakage Current: 250 μA
  • Mounting Type: Through-Hole
  • Package: TO-247-3
  • ECCN: EAR99
  • REACH Compliant: Yes
  • MSL Level: 1 (Unlimited Shelf Life)
  • Average Rectified Current per Diode: 24.5V DC
  • HTSUS Code: 8541.10.0080
