VAF1024 Cosel USA, Inc. VAF1024 Real Image VAF1024 real image 2 VAF1024 real image 3 VAF1024 label picture
Same model may have multiple batches, images only for reference.
VAF1024 Cosel USA, Inc. VAF1024 Real Image VAF1024 real image 2 VAF1024 real image 3 VAF1024 label picture
VAF1024 Cosel USA, Inc. VAF1024 Real Image VAF1024 real image 2 VAF1024 real image 3 VAF1024 label picture
Same model may have multiple batches, images only for reference.

VAF1024

Part No VAF1024
Manufacturer Cosel USA, Inc.
Catalog Board Mount AC DC Converters
Description AC/DC POWER SUPPLY
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Cosel USA, Inc.
Series VAF
Type Open Frame
Number of Outputs 1
Voltage - Input 85 ~ 264 VAC
Voltage - Output 1 24V
Current - Output (Maximum) 450mA
Power (Watts) 11W
Applications ITE (Commercial)
Features DC Input Capable, Universal Input
Operating Temperature Range -10°C ~ 71°C (With Derating)
Efficiency 81%
Mounting Style Through Hole
Package 5-DIP Module
Dimension 3.07" L x 1.42" W x 0.83" H (78.0mm x 36.1mm x 21.1mm)
Line Regulation 96mV
Load Regulation 150mV
Approvals CE, cURus, TUV
Win Source Part Number 799003-VAF1024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name VAF10
Introduction Date August 22, 2005
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian VAF1024 CAD Model

Description

The Cosel USA VAF series is an open frame type power supply with a through-hole mounting style.

  • Operating Temperature: -10°C to 71°C (with derating)
  • Input Type: DC Input Capable, Universal Input
  • Package Type: 5-DIP Module
  • Approvals: CE, cURus, TUV
  • Power: 11W
  • Input Voltage Range: 85 ~ 264 VAC
  • Number of Outputs: 1
  • Output Voltage: 24V
  • Efficiency: 81%
  • Family Name: VAF10
  • Line Regulation: 96mV
  • Load Regulation: 150mV
  • Dimensions: 3.07" L x 1.42" W x 0.83" H (78.0mm x 36.1mm x 21.1mm)
  • Maximum Current Output: 450mA
  • Supply and Demand Status: Balanced
  • Estimated EOL Date: 2024
