Same model may have multiple batches, images only for reference.

MGFS304815

Name: MGFS304815
Brand: Cosel USA, Inc.
SKU: 1078618
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	MGFS304815
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 15V / Isolated Module DC DC Converter 1 Output 15V 2A 18V - 76V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	MGFS (30W)
Package	Box
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	76V
Voltage - Output 1	15V
Current - Output (Max)	2A
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OVP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	89%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	1776-1351
Standard Package	1
Win Source Part Number	1078618-MGFS304815
Ultra Librarian 3D Model	Ultra Librarian MGFS304815 CAD Model

Alternative Products

Description

The MGFS304815 is a 30W isolated module DC-DC converter from Cosel USA, Inc.

Features: Remote On/Off, Overcurrent Protection, Overvoltage Protection
Package: Box
Mounting Type: Through Hole
Voltage Isolation: 1.5kV
Number of Outputs: One
Maximum Output Current: 2A
Input Voltage: 18V to 76V
Output Voltage: 15V
Efficiency: 89%
Application: ITE (Commercial)
Temperature Range: -40°C to 85°C (with derating)
Dimension: 2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
HTSUS: 8504.40.9580
Alternative parts (cross-reference): TEN 30-4813WIN, CCG302415S, MGFS302415, MGS301215, MGS302415, CCG304815S, and UHE-15/2000-D48-C
