STMGFS302412-N1 Real Image
Same model may have multiple batches, images only for reference.

STMGFS302412-N1

Part No STMGFS302412-N1
Manufacturer Cosel USA, Inc.
Catalog External/Internal (Off - Board) DC DC Converters
Description DC/DC CONVERTER 12V 30W / Enclosed DC DC Converter 1 Output 12V 2.5A 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board) - DC DC Converters
Mfr Cosel USA, Inc.
Series STMGFS (30W)
Package Box
Type Enclosed
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Number of Outputs 1
Voltage - Output 1 12V
Current - Output (Max) 2.5A
Power (Watts) 30W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Efficiency 89%
Temperature Range - Operating -20°C ~ 70°C (With Derating)
Mounting Type Chassis Mount
Size / Dimension 4.61" L x 2.05" W x 1.06" H (117.1mm x 52.1mm x 26.9mm)
Approval Agency CE
Base Product Number STMGFS302412
Standard Package 1
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1350916-STMGFS302412-N1
Ultra Librarian 3D Model Ultra Librarian STMGFS302412-N1 CAD Model

Description

The Cosel STMGFS302412-N1 is a 30W enclosed DC/DC converter designed for external/internal (off-board) power supply applications.

  • Type: Enclosed
  • Application: External/Internal (Off-Board) Power Supply
  • Length: 4.61" (117.1mm)
  • Width: 2.05" (52.1mm)
  • Height: 1.06" (26.9mm)
  • Input Voltage: 9V to 36V
  • Output Voltage: 12V
  • Efficiency: 89%
  • Operating Temperature Range: -20°C to 70°C
  • Approvals: CE
  • Series: STMGFS
  • Power: 30W
  • Application: ITE (Commercial)
  • Manufacturer: Cosel
  • Product: DC DC Converters
