Same model may have multiple batches, images only for reference.

SLPX681M220A4P3

Name: SLPX681M220A4P3
Brand: Cornell Dubilier Electronics (CDE)
SKU: 1307533
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SLPX681M220A4P3
Manufacturer	Cornell Dubilier Electronics (CDE)
Catalog	Aluminum Capacitors
Datasheet	SLPX681M220A4P3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Aluminum Electrolytic Capacitors
Mfr	Cornell Dubilier Electronics (CDE)
Series	SLPX
Package	Bulk
Capacitance	680 µF
Tolerance	±20%
Voltage - Rated	220 V
ESR (Equivalent Series Resistance)	293mOhm @ 120Hz
Lifetime @ Temp.	3000 Hrs @ 85°C
Temperature Range - Operating	-40°C ~ 85°C
Polarization	Polar
Applications	General Purpose
Ripple Current @ Low Frequency	2.62 A @ 120 Hz
Ripple Current @ High Frequency	3.85 A @ 20 kHz
Lead Spacing	0.394" (10.00mm)
Dimension	0.866" Dia (22.00mm)
Height - Seated (Max)	1.772" (45.00mm)
Mounting Type	Through Hole
Package / Case	Radial, Can - Snap-In
Standard Package	100
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0040
Win Source Part Number	1307533-SLPX681M220A4P3
Ultra Librarian 3D Model	Ultra Librarian SLPX681M220A4P3 CAD Model

Description

The Cornell Dubilier Electronics (CDE) SLPX series aluminum electrolytic capacitor is a general-purpose component that is ideal for a wide range of applications.

Capacitance: 680 µF
Voltage Rating: 220 V
Tolerance: ±20%
ESR: 293mOhm @ 120Hz
Design: Polarized
Mounting Type: Through-hole
Package: Radial can
Diameter: 0.866" (22.00mm)
Height: 1.772" (45.00mm)
Operating Temperature: -40°C to 85°C
Lifetime: 3000 Hrs @ 85°C
Packaging: Bulk
Standard Package: 100 units
Status: Obsolete
