Same model may have multiple batches, images only for reference.
105HC3600K2EM8 Real Image
Same model may have multiple batches, images only for reference.

105HC3600K2EM8

Part No 105HC3600K2EM8
Manufacturer Cornell Dubilier Electronics (CDE)
Catalog Film Capacitors
Description CAP FILM 1UF 10% 600VAC CHAS MT / 1 µF Film Capacitor 600V Polypropylene (PP) Nonstandard
Datasheet
105HC3600K2EM8 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Film Capacitors
Mfr Cornell Dubilier / Illinois Capacitor
Series HC3
Package Bulk
Capacitance 1 µF
Tolerance ±10%
Voltage Rating - AC 600V
Dielectric Material Polypropylene (PP)
ESR (Equivalent Series Resistance) 0.5 mOhms
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Chassis Mount
Package / Case Nonstandard
Dimension 2.205" L x 1.189" W (56.00mm x 30.20mm)
Height - Seated (Max) 2.618" (66.50mm)
Termination Threaded, Female
Applications Conduction Cooled; High Pulse, DV/DT
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.25.0055
Other Names 1572-1558
Standard Package 2
Win Source Part Number 1062880-105HC3600K2EM8
Ultra Librarian 3D Model Ultra Librarian 105HC3600K2EM8 CAD Model

Description

This is an HC3 series film capacitor from Cornell Dubilier / Illinois Capacitor that comes with a capacitance of 1 µF and a tolerance of ±10%.

  • Voltage Rating (AC): 600V
  • Application: Used for conduction cooled and high pulse, DV/DT applications
  • Termination: Non-standard capacitor that is threaded and female terminated
  • Package: Bulk
  • Standard Package: Contains 2 capacitors
  • Dielectric Material: Polypropylene (PP)
  • Operating Temperature Range: Between -40°C to 85°C
  • Dimensions: 2.205" L x 1.189" W (56.00mm x 30.20mm)
  • RoHS Compliant: Yes
