The CTX200-1 is a current transformer manufactured by Cooper Bussmann, Inc. It is designed to accurately measure alternating current (AC) without direct electrical contact with the conductor. This device is commonly used in power monitoring, load management, and energy metering applications to provide reliable current measurements for various electrical systems.

Applications:

• Power Monitoring
• Load Management
• Energy Metering
• Motor Control
• Industrial Automation

Features:

• Non-Invasive Current Measurement
• High Accuracy
• Wide Current Range
• Compact Size
• Easy Installation

Benefits:

• Safe Current Measurement without direct electrical connection
• Precise Monitoring of electrical current
• Versatile use in various current ranges
• Space-saving design
• Simplified Installation Process

Technical Specifications:

The CTX200-1 typically has a turns ratio that translates the primary current to a lower secondary current, typically a few milliamps, which can then be easily measured by standard instruments. The current range often varies, but many versions can measure up to 200 Amps or more. It is crucial to refer to the specific datasheet from Cooper Bussmann for details on the turns ratio, accuracy, operating frequency range, burden resistance, and physical dimensions.

Given its END-OF-LIFE status, alternative current transformers might need to be considered for new designs.
