Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Comchip Technology
Series -
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 12V (Max)
Voltage - Breakdown (Min) 13V
Voltage - Clamping (Max) @ Ipp 25V
Current - Peak Pulse (10/1000µs) 1A (8/20µs)
Power - Peak Pulse 25W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 12pF @ 1MHz
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Supplier Device Package 0402C/SOD-923F
Base Product Number CPDQC12
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1362391-CPDQC12V-HF
Ultra Librarian 3D Model Ultra Librarian CPDQC12V-HF CAD Model

Description

The CPDQC12V-HF is a zener transient voltage suppressor diode designed for circuit protection against voltage transients in various electronic devices, manufactured by Comchip Technology.

  • Series: CPDQC12
  • Mounting Type: Surface Mount
  • Package: 0402 (1006 Metric)
  • Reverse Standoff Voltage: 12V
  • Breakdown Voltage: 13V
  • Clamping Voltage: 25V @ 1A (10/1000µs)
  • Power Peak: 25W
  • Power Line Protection: No
  • Capacitance: 12pF @ 1MHz
  • Application: General Purpose
  • Temperature Range: -40°C to 125°C
