The UPG2012TK-E2-A is an RF/IF and RFID component manufactured by CEL.

• Status: This component is obsolete (EOL).
• Package: and is supplied in a 6-Minimold package.
• Impedance: It has an impedance of 50 Ohm.
• Circuit: a circuit of SPDT.
• Topology: and a topology of reflective.
• Frequency Range: The frequency range is from 500MHz to 2.5GHz.
• Isolation: and the isolation @ frequency is 30dB @ 2.5GHz (typ).
• Insertion Loss: The insertion loss @ frequency is 0.3dB @ 2.5GHz.
• P1dB: and the P1dB is 24dBm (typ) IP1dB.
• RF Type: The RF type is 802.15.1/Bluetooth, Cellular, PCS, WLAN, WLL.
• Operating Supply Voltage: The operating supply voltage ranges from 2.7V to 3V.
• Alternative Parts: Alternative parts (cross-reference) for this component are UPG2012TK-E2 and UPG2012TK.
• Introduction Date: The UPG2012TK-E2-A was introduced on September 26, 2005.
• EOL Date: and its estimated EOL date is obsolete.
