PS2805C-1-F3-A Real Image PS2805C-1-F3-A Real Image
Same model may have multiple batches, images only for reference.
PS2805C-1-F3-A Real Image PS2805C-1-F3-A Real Image
PS2805C-1-F3-A Real Image PS2805C-1-F3-A Real Image
Same model may have multiple batches, images only for reference.

PS2805C-1-F3-A

Part No PS2805C-1-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 2.5KV TRANS 4SOIC
Datasheet
PS2805C-1-F3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 10μs, 7μs
Rise and Fall Time 5μs, 7μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 30mA
Forward Voltage 1.2V
Continuous forward current- Max 30mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SSOP
Win Source Part Number 004458-PS2805C-1-F3-A
Family Name PS2805C-1
Introduction Date August 13, 2007
ECCN EAR99
Country of Origin Japan, Taiwan
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PS2805C-1-F3-A CAD Model

Description

The CEL PS2805C-1-F3-A is an optoisolator with a transistor output that is ideal for use in power supplies and industrial controls.

  • Product Name: CEL PS2805C-1-F3-A
  • Application: Power supplies and industrial controls
  • Isolation Voltage: 2500Vrms
  • Maximum Output Voltage: 80V
  • Minimum DC Current Transfer Ratio: 50% @ 5mA
  • Maximum DC Current Transfer Ratio: 400% @ 5mA
  • Switching Turn-On Time: 10μs
  • Switching Turn-Off Time: 7μs
  • Rise Time: 5μs
  • Fall Time: 7μs
  • Channel Output Current: 30mA
  • Continuous Forward Current: 30mA
  • Package: 4-SSOP
  • Temperature Range: -55°C to 100°C
