PS2565L-1-E3-A CEL
Same model may have multiple batches, images only for reference.

PS2565L-1-E3-A

Part No PS2565L-1-E3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 5KV TRANS 4SMD
Datasheet
PS2565L-1-E3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Obsolete(EOL)
Number of Channels 1
Isolation Voltage 5000Vrms
Minimum DC Current Transfer Ratio 80% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Rise and Fall Time 3μs, 5μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.17V
Continuous forward current- Max 80mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SMD
Win Source Part Number 111550-PS2565L-1-E3-A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PS2565L-1-E3-A CAD Model

Description

The CEL PS2565L-1-E3-A is a single-channel optoisolator designed for use in AC and DC input applications.

  • Isolation Voltage: 5000Vrms
  • Minimum DC Current Transfer Ratio: 80%
  • Operating Voltage: 4.5V to 5.5V
  • Maximum Forward Voltage: 1.17V
  • Mounting Style: SMD (SMT)
  • Package: 4-SMD
  • Rise Time: 3μs
  • Fall Time: 5μs
  • Maximum Output Voltage: 80V
