LTA201-TR-B/125N Real Image
Same model may have multiple batches, images only for reference.

LTA201-TR-B/125N

Part No LTA201-TR-B/125N
Manufacturer Carling Technologies
Catalog Rocker Switches
Description SWITCH ROCKER SPST 15A 125V / Rocker Switch SPST 15A (AC) 125 V Panel Mount, Snap-In
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Rocker Switches
Mfr Carling Technologies
Series LTA
Package Bulk
Mounting Type Panel Mount, Snap-In
Circuit SPST
Switch Function On-Off
Current Rating (Amps) 15A (AC)
Voltage Rating - AC 125 V
Actuator Type Concave (Standard V) - Illuminated
Color - Actuator/Cap Red
Actuator Marking No Marking
Illumination Type, Color Neon, Red
Illumination Voltage (Nominal) 125 VAC
Termination Style Quick Connect - 0.250" (6.3mm)
Panel Cutout Dimensions Rectangular - 28.57mm x 13.97mm
Temperature Range - Operating 0°C ~ 85°C
Mechanical Life 100,000 Cycles
Electrical Life 100,000 Cycles
Base Product Number LTA201
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Names 103-05237000,LTA201TRB/125N,432-1284
Standard Package 1
Win Source Part Number 992611-LTA201-TR-B/125N
Ultra Librarian 3D Model Ultra Librarian LTA201-TR-B/125N CAD Model

Description

The LTA201-TR-B/125N is a SPST rocker switch from Carling Technologies.

  • Voltage Rating: 125 VAC
  • Current Rating: 15A (AC)
  • Mounting: Panel mounted and snap-in
  • Termination Style: Quick connect 0.250" (6.3mm)
  • Switch Function: On-Off
  • Actuator Type: Concave (standard V) - illuminated
  • Illumination Voltage (Nominal): 125 VAC
  • Illumination Type: Neon
  • Illumination Color: Red
  • Electrical Life: 100,000 cycles
  • Mechanical Life: 100,000 cycles
  • Applications: Appliances, power tools, and medical equipment
