CM102J3AS205QA7 Real Image
Same model may have multiple batches, images only for reference.

CM102J3AS205QA7

Part No CM102J3AS205QA7
Manufacturer C&K Components
Catalog Rocker Switches
Description SWITCH ROCKER SPST 16A 125V / Rocker Switch SPST 16A (AC) 125 V Panel Mount, Snap-In
Datasheet
CM102J3AS205QA7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Rocker Switches
Mfr C&K
Series CM
Package Tray
Mounting Type Panel Mount, Snap-In
Circuit SPST
Switch Function On-Off
Current Rating (Amps) 16A (AC)
Voltage Rating - AC 125 V
Actuator Type Concave (Curved) - Illuminated
Color - Actuator/Cap Amber
Actuator Marking No Marking
Illumination Type, Color Neon, Amber
Illumination Voltage (Nominal) 125 VAC
Termination Style Quick Connect - 0.250" (6.3mm)
Panel Cutout Dimensions Rectangular - 30.40mm x 11.20mm
Temperature Range - Operating -20°C ~ 80°C
Electrical Life 10,000 Cycles
Base Product Number CM102J
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Names -CM102J3AS205QA7,*CM102J3AS205QA7,2266-CM102J3AS205QA7,401-1356
Standard Package 50
Win Source Part Number 958822-CM102J3AS205QA7
Ultra Librarian 3D Model Ultra Librarian CM102J3AS205QA7 CAD Model

Description

The CM102J3AS205QA7 is a rocker switch that is part of the CM series.

  • Series: CM
  • Termination Style: Quick Connect 0.250" (6.3mm)
  • Panel Cutout Dimension: 30.40mm x 11.20mm
  • Circuit: SPST
  • Switch Function: On-Off
  • Actuator Type: Concave (curved)
  • Illumination Color: Neon Amber
  • Illumination Voltage (Nominal): 125 VAC
  • Illumination Type: Neon
  • Mechanical Life: Not specified
  • Electrical Life: 10,000 cycles
  • Mounting Type: Panel Mount, Snap-In
  • Temperature Range: -20°C ~ 80°C
