Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Circuit DPDT
Switch Function On-Mom
Current Rating (Amps) 15A (AC)
Voltage Rating - AC 125 V
Actuator Type Lever, Roller
Mounting Type Chassis Mount
Termination Style Quick Connect - 0.250" (6.3mm)
Operating Force 510gf
Release Force 57gf
Operating Position 0.718" (18.24mm)
Pretravel 0.281" (7.14mm)
Overtravel 0.062" (1.6mm)
Electrical Life 200,000 Cycles
Temperature Range - Operating -55°C ~ 85°C
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1551272-ADPDC2W04AC
Ultra Librarian 3D Model Ultra Librarian ADPDC2W04AC CAD Model
