MGA-25203-TR1G Broadcom Limited MGA-25203-TR1G real image12636 MGA-25203-TR1G real image
Same model may have multiple batches, images only for reference.
MGA-25203-TR1G Broadcom Limited MGA-25203-TR1G real image12636 MGA-25203-TR1G real image
MGA-25203-TR1G Broadcom Limited MGA-25203-TR1G real image12636 MGA-25203-TR1G real image
Same model may have multiple batches, images only for reference.

MGA-25203-TR1G

Part No MGA-25203-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description 5.1 - 5.9 GHz WiFi and WiMAX Power Amplifi er (3x3mm) | IC AMP WIFI WIMAX 4.9GHZ-5.9GHZ
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Tape and Reel
Status Obsolete
Frequency 4.9GHz ~ 5.9GHz
P1dB 29dBm
Gain 30dB
RF Type WiFi, WiMAX
Supply Voltage (V) 3V ~ 5V
Test Frequency 5.4GHz
Manufacturer Package 17-LCC
Manufacturer Pack Quantity 3,000
MSL Level 3 (168 Hours)
Win Source Part Number 1221827-MGA-25203-TR1G
Manufacturer Homepage www.avagotech.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name MGA-25203
Introduction Date September 01, 2009
ECCN 5A991.g
Country of Origin Malaysia, Republic of Korea
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian MGA-25203-TR1G CAD Model

Description

The Broadcom Limited MGA-25203-TR1G is an obsolete component designed for use in RF/IF and RFID applications. It has a frequency range of 4.9GHz to 5.9GHz and a gain of 30dB.

  • Frequency Range: 4.9GHz to 5.9GHz
  • Gain: 30dB
  • Package: 17-LCC
  • Test Frequency: 5.4GHz
  • Popularity: High
  • Supply and Demand: Limited
  • Estimated EOL Date: Obsolete
  • Manufacturer: Broadcom Limited
