HSMH-C265 Real Image HSMH-C265 real image HSMH-C265 label picture HSMH-C265 label picture 2
Same model may have multiple batches, images only for reference.
HSMH-C265 Real Image HSMH-C265 real image HSMH-C265 label picture HSMH-C265 label picture 2
HSMH-C265 Real Image HSMH-C265 real image HSMH-C265 label picture HSMH-C265 label picture 2
Same model may have multiple batches, images only for reference.

HSMH-C265

Part No HSMH-C265
Manufacturer Broadcom Limited
Catalog LED Indication - Discrete
Description LED Uni-Color Red 660nm 2-Pin Chip LED T/R / LED RED CLEAR 1305 SMD REV
Datasheet
HSMH-C265 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Optoelectronics
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Color Red
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 17mcd
Lens Style/Size Rectangle with Flat Top, 1.20mm x 1.25mm
Forward Voltage 1.8V
Current - Test 20mA
Viewing Angle 170°
Mounting Surface Mount, Bottom Entry
Wavelength - Dominant 639nm
Wavelength - Peak 660nm
Case / Package Chip LED
Height (Max) 1.10mm
Win Source Part Number 1044015-HSMH-C265
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name HSMH-C265
Introduction Date January 01, 2002
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian HSMH-C265 CAD Model

Description

The HSMH-C265 is a surface mount, bottom entry chip LED. HSMH-C265 is manufactured by Broadcom Limited.

  • Forward Voltage: 1.8V
  • Viewing Angle: 170 degrees
  • Lens: rectangular, colorless and clear, flat top style, 1.20mm x 1.25mm
  • Millicandela Rating: 17mcd
  • Dominant Wavelength: 639nm
  • Peak Wavelength: 660nm
  • Height: 1.10mm
  • Halogen-Free: compliant
  • Supply and Demand Status: sufficient
  • Estimated EOL Date: 2026
