HEDM-5500#B06 Real Image
Same model may have multiple batches, images only for reference.

HEDM-5500#B06

Part No HEDM-5500#B06
Manufacturer Broadcom Limited
Catalog Encoders
Description ROTARY ENCODER OPTICAL 1000PPR / Rotary Encoder Optical 1000 Quadrature (Incremental) Vertical
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Encoders
Mfr Broadcom Limited
Series HEDM
Package Bulk
Product Status Active
Programmable Not Verified
Encoder Type Optical
Output Type Quadrature (Incremental)
Pulses per Revolution 1000
Voltage - Supply 5V
Actuator Type 1/4" Open Center
Detent No
Built in Switch No
Mounting Type Chassis Mount, Motors
Orientation Vertical
Termination Style Terminal Pins
Base Product Number HEDM-5500
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.70.4500
Win Source Part Number 920140-HEDM-5500#B06
Ultra Librarian 3D Model Ultra Librarian HEDM-5500#B06 CAD Model

Description

The Broadcom Limited 920140-HEDM-5500#B06 is a sensor and transducer component that falls under the category of encoders.

  • Series: HEDM
  • Package: bulk
  • Standard Package Quantity: 50 pieces
  • Win Source Part Number: 920140-HEDM-5500#B06
  • Manufacturer: Broadcom Limited
  • Termination Style: terminal pins
  • Orientation: vertical
  • Output Type: quadrature (incremental)
  • Actuator Type: 1/4" open center
  • Programmable: not programmable
  • Built-in Switch: does not have a built-in switch
  • Type: optical encoder
  • Pulses per Revolution: 1000
  • Detent: no detent specified
  • Voltage Supply: 5V
  • Mounting Type: chassis mount or motors
  • REACH: not affected by REACH regulations
  • ECCN: EAR99
  • MSL Level: 1, meaning it is unlimited
  • HTSUS Code: 8543.70.4500
  • Status: active
