Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Optoelectronics
Estimated Pruduction Lead Time 23 Weeks
Features Display Modules - LED Character and Numeric Green 7-Segment +/-1 (overflow) Character Common Anode 1.85V 8mA 0.531" H x 0.402" W x 0.169" D (13.50mm x 10.20mm x 4.30mm) 8-DIP (0.600", 15.20mm)
Manufacturer Broadcom Limited
Series HDSP-098x
Package Bulk
Package 8-DIP (0.600", 15.20mm)
Family Name HDSP-0983
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.40.2000
Quantity per package 25
Popularity High
Supply and Demand Status Balance
Win Source Part Number 920101-HDSP-0983
Ultra Librarian 3D Model Ultra Librarian HDSP-0983 CAD Model

Description

The Broadcom Limited HDSP-098x series is a display module that is designed to display numeric and character data from Broadcom Limited.

  • Display Type: Green 7-segment display module
  • Anode/Cathode Type: Common anode
  • Character Display: +/-1 (overflow)
  • Voltage Rating: 1.85V
  • Current Rating: 8mA
  • Applications: Optoelectronics applications
  • Dimensions: 0.531" H x 0.402" W x 0.169" D (13.50mm x 10.20mm x 4.30mm)
  • Package: 8-DIP (0.600", 15.20mm)
  • Packaging: Bulk
  • REACH: Unaffected
  • Estimated Production Lead Time: 23 weeks
  • MSL Level: 1 (Unlimited)
