HDSM-283B Broadcom Limited – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HDSM-283B

Part No HDSM-283B
Manufacturer Broadcom Limited
Catalog LED Character and Numeric
Description DISPLAY 7SEG 0.28\
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Characters 1
Size / Dimension 0.425" H x 0.295" W x 0.124" D (10.80mm x 7.50mm x 3.15mm)
Digit/Alpha Size 0.28" (7.00mm)
Display Type 7-Segment
Common Pin Common Cathode
Color Blue
Voltage - Forward (Vf) (Typ) 3.3V
Current - Test 20mA
Millicandela Rating 6mcd
Wavelength - Peak 462nm
Power Dissipation (Max) 100mW
Case / Package 12-SMD, No Lead, 11 Pads
Package Tape & Reel (TR);Cut Tape (CT);Reel
Supply and Demand Status Limited
Win Source Part Number 1565632-HDSM-283B
Ultra Librarian 3D Model Ultra Librarian HDSM-283B CAD Model
