HCPL-J312-000E Broadcom Limited HCPL-J312-000E Real Image HCPL-J312-000E real image
Same model may have multiple batches, images only for reference.
HCPL-J312-000E Broadcom Limited HCPL-J312-000E Real Image HCPL-J312-000E real image
HCPL-J312-000E Broadcom Limited HCPL-J312-000E Real Image HCPL-J312-000E real image
Same model may have multiple batches, images only for reference.

HCPL-J312-000E

Part No HCPL-J312-000E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 3.75KV GATE DRIVER 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise and Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Forward Voltage 1.6V
Continuous forward current- Max 25mA
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting Through Hole
Case / Package 8-DIP
Approvals CSA, IEC/EN/DIN, UR
Win Source Part Number 1042814-HCPL-J312-000E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-J312-000E CAD Model

Description

The 1042814-HCPL-J312-000E is an optical coupling technology product from Broadcom Limited that is used in various applications.

  • Popularity: medium
  • Supply and Demand Status: balanced
  • Win Source Part Number: 1042814-HCPL-J312-000E
  • Mounting Style: through-hole
  • Isolation Voltage: 3750Vrms
  • Common Mode Transient Immunity: 25kV/μs
  • Approvals: CSA, IEC/EN/DIN, and UR
  • Pulse Width Distortion: 300ns
  • Maximum Propagation Delay: 500ns
  • Temperature Range: -40°C to 100°C
