HCPL-7840-000E

Name: HCPL-7840-000E
Brand: Broadcom Limited
SKU: 142096
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-7840-000E
Manufacturer	Broadcom Limited
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	OptoCoupler 1-CH 5V 8-Pin PDIP Tube / IC OPAMP ISOLATION 100KHZ 8DIP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Broadcom Limited
Packaging	Tube/Rail
Status	Active
Amplifier Type	Isolation
Number of Circuits	1
Output Type	Differential
-3db Bandwidth	100kHz
Current - Input Bias	500nA
Voltage - Input Offset	300μV
Operating Supply Current	10.86mA
Channel Output Current	15.5mA
Supply Voltage - Operating	4.5 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	Through Hole
Case / Package	8-DIP
Win Source Part Number	088243-HCPL7840-000E
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	HCPL-7840
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Singapore, Thailand
Halogen Free	Not Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian HCPL-7840-000E CAD Model

Alternative Products

Alternative Product Part Number	Manufacturer	Package	Country	Similarity
HCPL-7840	BROADCOM	DIP-8	United States	PIN-TO-PIN
HCPL-7840#060E	BROADCOM	DIP-8	United States	PIN-TO-PIN
HCPL-7840-060	BROADCOM	DIP-8	United States	PIN-TO-PIN
HCPL-7840-E	BROADCOM	DIP-8	United States	PIN-TO-PIN

Description

The HCPL-7840-000E is an isolation amplifier manufactured by Broadcom Limited.

Output Type: Differential
-3db Bandwidth: 100kHz
Current Input Bias: 500nA
Voltage Input Offset: 300μV
Mounting: Through-Hole
Operating Temperature: -40°C to 85°C
Operating Supply Voltage: 4.5 V to 5.5 V
Operating Supply Current: 10.86mA
Package: 8-DIP
Alternative Parts: HCPL-7840#00Y, HCPL-7840#060, HCPL-7840#50Y, and HCPL-7840-060.
