HCPL-6750 Real Image
Same model may have multiple batches, images only for reference.

HCPL-6750

Part No HCPL-6750
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 1.5KV 4CH DARL 16FLATPAK  /  Optoisolator Darlington Output 1500VDC 4 Channel 16-Flatpack
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators>Optoisolators - Transistor, Photovoltaic Output
Mfr Broadcom Limited
Package Tube
Number of Channels 4
Voltage - Isolation 1500VDC
Current Transfer Ratio (Min) 200% @ 5mA
Turn On / Turn Off Time (Typ) 2µs, 8µs
Input Type DC
Output Type Darlington
Voltage - Output (Max) 20V
Current - Output / Channel 40mA
Voltage - Forward (Vf) (Typ) 1.4V
Current - DC Forward (If) (Max) 10 mA
Vce Saturation (Max) 110mV
Temperature Range - Operating -55°C ~ 125°C
Mounting SMD (SMT)
Package / Case 16-Flatpack
Supplier Device Package 16-Flatpack
Base Product Number HCPL-6750
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Other Names 516-2993,HCPL-6750-ND
Standard Package 1
Win Source Part Number 1224537-HCPL-6750
Ultra Librarian 3D Model Ultra Librarian HCPL-6750 CAD Model

Description

The Broadcom Limited HCPL-6750 is an optoisolator with a Darlington output.

  • Current Transfer Ratio: 200% @ 5mA
  • Maximum Forward Current: 10 mA
  • Voltage Isolation: 1500VDC
  • Mounting Type: SMD (SMT)
  • Channels: 4
  • Package Size: 16-Flatpack
