HCPL-3760-500E Real Image HCPL-3760-500E Real Image
Same model may have multiple batches, images only for reference.
HCPL-3760-500E Real Image HCPL-3760-500E Real Image
HCPL-3760-500E Real Image HCPL-3760-500E Real Image
Same model may have multiple batches, images only for reference.

HCPL-3760-500E

Part No HCPL-3760-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV DARL 8DIP GW
Datasheet
HCPL-3760-500E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Switching Turn-On and Turn-Off Time 4.5μs, 8μs
Rise and Fall Time 14μs, 0.4μs
Input Type AC, DC
Output Type Darlington
Maximum Output Voltage 20V
Channel Output Current 30mA
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 1042706-HCPL-3760-500E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL-3760-500E CAD Model

Description

The Broadcom Limited HCPL-3760-500E is an SMD optocoupler that features a Darlington output type and an AC/DC input type. Broadcom Limited

  • Output Type: Darlington
  • Input Type: AC/DC
  • Channels: 1
  • Isolation Voltage: 3750Vrms
  • Turn-on Time: 4.5μs
  • Turn-off Time: 8μs
  • Rise Time: 14μs
  • Fall Time: 0.4μs
  • Package: 8-DIP Gull Wing
  • Output Current: 30mA
  • Application: Suitable for use in isolators.
