HCPL-060L Real Image HCPL-060L Real Image
Same model may have multiple batches, images only for reference.
HCPL-060L Real Image HCPL-060L Real Image
HCPL-060L Real Image HCPL-060L Real Image
Same model may have multiple batches, images only for reference.

HCPL-060L

Part No HCPL-060L
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description High Speed LVTTL Compatible 3.3 Volt Optocouplers | OPTOISO 3.75KV OPN COLLECTOR 8SO
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Minimum) 10kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Current - Output / Channel 50mA
Data Rate 15MBd
Propagation Delay tpLH / tpHL (Maximum) 75ns, 75ns
Rise / Fall Time 24ns, 10ns
Voltage - Forward (Vf) 1.5V
Current - DC Forward (If) (Maximum) 20mA
Supply Voltage (V) 2.7V ~ 3.6V, 4.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO Tall
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 731139-HCPL-060L
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HCPL-060L CAD Model

Description

The Broadcom Limited HCPL-060L is a high-gain, high-speed optocoupler. It is manufactured by Broadcom Limited.

  • Win Source Part Number: 731139
  • Applications: High-performance digital isolation
  • Output Stage: Open collector with Schottky clamping
  • Package: 8-SO Tall
  • Data Rate: 15MBd
